Parts for:

Hitachi F1500 Planer Jointer

Search Parts:

Search Parts

Only common repair parts are available for purchase. If a part does not have add to cart button it's not available for purchase on Toolbarn. Please do not contact customer service for availability on these items.

Click To Hide Unavailable Parts

Please scroll left/right table for more info!

Ref	Description	Qty
107	MACHINE SCREWS M5x12	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
108	SPRING WASHER M5 C10FC	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
11	BOLT M10 X 50 (10 PC) CB75F	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
114	BOLT M8x16 (10pc) C10RAS P12RA	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
115	SPRING WASHER M8 (10pc)	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
117	ROLL PIN D4x28 (10pc) F1000A	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
118	WASHER M10 (10pc) C8FB2 C12FSA	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
12	LOCK WASHER M10 (10 PCS)	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
120	NUT M6 (10 PCS) C12LSH/RSH	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
122	FEATHER KEY 4x4x12 C10FS P12RA	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
124	SCREWS M5x16 (10 pc) NV50A1	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
125	Hex Nut M5 (10pc) NR83A NV50A1	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
126	KNOB F1500	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
127	ROLL PIN D5x25 (10pc) CB75F	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
128	WASHER M12 C8FB2 C10FS 10PS	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
129	RETAINING RING D13 D15SHAFT	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
132	MACHINE SCREW M6x10 (10pc)	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
134	BOLT M6X12 (10 PCS) P12R P12RA	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
135	WASHER M6 C10FS C12FSA 10PS	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
136	Collar for C12Y	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
157	RETAINING RING VB16Y D28SHAFT * Obsolete *	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
16	BOLT M10X30 (10 PCS) CB75F	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
163	NUT M12 (10 PCS) C10FS C8FB2	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
165	SCREW M6x16 C15FB CB75F 10PS	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
167	BOLT M10x35 (10pc) P12RA P12R	Add to Cart 5 Required Quantity Required Quantity Required popup block Please enter a quantity of "5" or more to proceed.
173	FEED ROLLER (B) F1500A	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
178	FEATHER KEY VB16Y	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
18	BOLT M8x30 (10pc) CC14SC	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
180	NUT M10 (10 PCS) C10FC/C10FC2	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
181	LOCK NUT M10 C15FB 10PS	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
183	Screw (M) for C12FA	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
189	SCREW M6 X 25 (10 PCS) CD14F	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
193	LOCK NUT M8 (10pc) C8FB2	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
199	Ball Bearing	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
206	WASHER (R) C12FSA	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
21	D5 x 28 Roll Pin for F1000A (10 PS) * Obsolete *	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
211	HEX SOCKET HD BOLT M8x25 10PS	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
214	SPRING (C) C8FB2 C10FS C15FB	Add to Cart 10 Required Quantity Required Quantity Required popup block Please enter a quantity of "10" or more to proceed.
217	ROLL PIN D5x20 (10 PCS) CB75F	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
24	MASH.SCREW M6x12 C10FC 10PS	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
240	BOLT M10x40 F1000A	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
249	SET SCREW M8x8 C10FS C8FB2	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
25	LOCK WASHER M6 CC14SC NR83A	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
254	Brake Lining for PU100F	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
256	ROLL PIN D6x30 (10pc) CC14SC	Add to Cart 3 Required Quantity Required Quantity Required popup block Please enter a quantity of "3" or more to proceed.
260	Brake Spring for CB100F	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
262	BOLT M8x30 (10pc) CB75F P12R	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
264	BOLT M12X30 (10 PCS) CB75F	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
267	BALL BEARING 6003VVCMPS2L	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
269	RetainingRingC-TYPEforD17shaft	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
279	RetainingRing forD35shaft 10PS	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
285	HEX SOC. SET SCREW M6x8 C10FC2	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
286	BALL BEARING 6203VVCMPS2L H65	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
288	BALL BEARING 6205VVCMPS2L C12Y	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
289	RETAINING RING P12RA D52SHAFT	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
290	SPLIT PIN D3x15 (10pc) CC14SB	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
291	M5 x 5 x 30 Key for RW200	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
296	BALL BEARING 6005VVPS2L	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
315	HEX SOCKET SET SCREW M6x10 1EA * Obsolete *	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
33	RIVET D2.5x4.8 C15FB (10 Pack)	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
348	ROLL PIN D4x25 (10pc) C12FSA	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
363	HIGH TENSION BOLT M8x16 CB75F	Add to Cart 16 Required Quantity Required Quantity Required popup block Please enter a quantity of "16" or more to proceed.
371	MACHINE SCREW M5x10 10PS	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
389	HEX.SOCKET SET SCREW M6x6 1EA	Add to Cart 5 Required Quantity Required Quantity Required popup block Please enter a quantity of "5" or more to proceed.
394	RETAINING RING H45MR 10PS	Add to Cart 8 Required Quantity Required Quantity Required popup block Please enter a quantity of "8" or more to proceed.
398	FLATHD SCREW M6x16 C8FB2	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
399	D3 x 6 Roll Pin for F1000A (10 PS)	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
4	LOCK WASHER M12 (10pc) C10FS	Add to Cart 6 Required Quantity Required Quantity Required popup block Please enter a quantity of "6" or more to proceed.
401	SPECIAL WASHER C15FB	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
407	THRUST BEARING P12R/P12RA	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
41	D2.5 x 6.4 Rivet for F1500 (10 PS)	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
410	Washer (A) for CB100F	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
412	LOCK NUT M12 C8FB2	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
42	RETAINING RING DH24PB D30SHAFT	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
421	BOLT M8x25 (10pc) CC14SC	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
424	D5 x 10 Roll Pin for F1500 (10 PS)	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
43	BACK METAL (B) 250mm F1500 (PACK OF 2)	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
432	RETAINING RING DH50MB DH22PG	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
435	NYLOCK HEX BOLT M8x30 (10PCS)	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
438	FLAT HD SCREW M4x16 GP21SA10PS	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
44	HIGH TENTION BOLT M8x13 F1500	Add to Cart 10 Required Quantity Required Quantity Required popup block Please enter a quantity of "10" or more to proceed.
444	BOLT WASHER M5 (10PCS) C8FB2	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
45	BALL BEARING 6306VVCMPS2L CB75	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
455	WASHER M8 CC12Y CC14 D13 10PS	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
47	SCREW M6x20 C10FS	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
50	SCREW M4x6 (10pc) DV14DVA	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
53	SPRING WASHER M4 (10pc)	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
603	MACHINE SCREW M4x12	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
604	WASHER M4 (10pc) DH40MA/MB	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
607	Cord Armor for RW200	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
608	SCREW M4x6 H65 H85 10PS	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
61	ROLL PIN D6x36 (10pc) H65 H85	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
617	NYLON CLIP CB75F	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
630	CABLE TIE C10FS C12FDH C12LDH	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
65	Hex Sock HD Bolt M10x30 (10pc)	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
67	BOLT M10x20 (10pc) CC14/SB/SC	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
672	HexHDBoltM10x25 F1000A 10PS * Obsolete *	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
7	BOLT M8x35 C10FCH	Add to Cart 8 Required Quantity Required Quantity Required popup block Please enter a quantity of "8" or more to proceed.
704	BOLT M6x16 (10pc) C10FS C10RA	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
707	Hex SockET HD. Bolt M6x16 NR83AA 10PS	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
711	WRENCH 13x17mm D13Y/YK D13VF/VG	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
8	HEX NUT M8 (10pc) C10RA C10FS	Add to Cart 8 Required Quantity Required Quantity Required popup block Please enter a quantity of "8" or more to proceed.
83	MACHINE SCREW M4x8 (10pc) C7SB	Add to Cart 2 Required Quantity Required Quantity Required popup block Please enter a quantity of "2" or more to proceed.
85	LINER (A) CB75F	Add to Cart 8 Required Quantity Required Quantity Required popup block Please enter a quantity of "8" or more to proceed.
86	LINER (A) CB75F	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.
95	GRIP (A) C12Y CB75F	Add to Cart 1 Required Quantity Required Quantity Required popup block Please enter a quantity of "1" or more to proceed.
99	LOCK WASHER M3.5 PB20	Add to Cart 4 Required Quantity Required Quantity Required popup block Please enter a quantity of "4" or more to proceed.

VIEW CART
